G63 Series Mechanical CNC Precision Leveler Manufacturer

G63 Series Mechanical CNC Precision Leveler

G63 Series CNC Mechanical Precision Leveler with 63mm rollers is ideal for thin and medium metal sheets, customizable widths, produced by Zhongan as a direct manufacturer for reliable quality.

Model:
G63
Brand:
Zhongan Machinery
Roller Diameter (mm):
Φ63mm
Width (mm):
500, 800, 1300, 1600, etc. (customizable according to product requirements)
Maximum Plate Thickness:
8.0mm
Leveling Speed:
0-10m/min

Quantity:
Availability:





Inquire

Leveler Description

Specifications

Catalogue

FAQ

G63 Series Mechanical CNC Precision Leveler Description：

Parameters of G63 series leveling machines (suitable for thin and medium materials)

Roller diameter (mm): Φ63mm

Width (mm): 500, 800, 1300, 1600, etc. (customizable according to product requirements)

Number of rollers: upper 9 + 10 lower = 19 rollers

Rated plate thickness for full width: 1.2-2.4mm

Maximum plate thickness : 8.0mm

Minimum leveling length: 126mm (can not below twice of the roller diameter)

Leveling speed: 0-10m/min

Leveling accuracy: Aroud 0.5mm/㎡（final accuracy subject to equipment testing)

Applicable objects: sheet metal processing industry, etc.

G63 Series Mechanical CNC Precision Leveler - Zhongan

G63 Series Mechanical CNC Precision Leveler Specifications：

Table for Leveled Width Range of G63 Series(Material Q235/Yield Strength 235MPa)
Thickness\Width	G63-500-19	G63-800-19	G63-1300-19	G63-1600-19
1.2-2.4	500	800	1300	1600
4.8	400	660	1080	1330
6.4	300	500	810	1000
8	250	400	650	800
