G32 Series Mechanical CNC Precision Leveler Manufacturer

G32 Series Mechanical CNC Precision Leveler

Zhongan G32 Series CNC Mechanical Leveler uses 32mm rollers for high-precision thin sheet leveling, customizable to width, factory-direct manufacturer offering reliable performance and cost advantage.

Model:
G32
Brand:
Zhongan Machinery
Roller Diameter (mm):
Φ32mm
Width (mm):
300, 500, 800,1300 etc. (customizable according to product requirements)
Maximum Plate Thickness:
2.4mm
Leveling Speed:
0-10m/min

Quantity:
Availability:





Inquire

Leveler Description

Specifications

Catalogue

FAQ

G32 Series Mechanical CNC Precision Leveler Description：

Parameters of G32 series leveling machines (suitable for thin materials)

Roller diameter (mm): Φ32mm

Width (mm): 300, 500, 800,1300 etc. (customizable according to product requirements)

Number of rollers: upper 9 + 10 lower = 19 rollers

Rated plate thickness for full width: 0.4-1.2mm

Maximum plate thickness : 2.4mm

Minimum leveling length: 64mm (can not below twice of the roller diameter)

Leveling speed: 0-10m/min

Leveling accuracy: Around 0.5mm/㎡（final accuracy subject to equipment testing)

Applicable objects:electronic IC industry etc.

G32 Series Mechanical CNC Precision Leveler - Zhongan

G32 Series Mechanical CNC Precision Leveler Specifications：

Table for Leveled Width Range of G32 Series(Material Q235/Yield Strength 235MPa)
Thickness\Width	G32-300-19	G32-500-19	G32-800-19	G32-1300-19
0.4-1.2	300	500	800	1300
1.6	200	330	530	660
2.0	150	250	400	500
2.4	120	200	290	400
